CTN Series Wet Drum Magnetic Separator

The CTN type wet permanent magnet drum magnetic separator is a counter-current tank structure separator, suitable for operational stages with high requirements for ore recovery.It is widely used in iron ore mines at home and abroad .BGRIMM developed China's first wet permanent magnet drum magnetic separator, which has made considerable progress over the years.Currently, the Ф1200 mm series magnetic separators have been widely used, and the Ф1500 mm series is gradually becoming the preferred magnetic separation equipment for newly built concentrators.



Applications：

It is used for the wet roughing operation of magnetic ores such as magnetite, pyrrhotite, roasted ore, and ilmenite
Technical Features：
  • 01
    It adopts high-quality strontium ferrite or high-performance magnetic steel
  • 02
    Its drum surface magnetic field strength ranges from 100 mT to 600 mT
  • 03
    Large throughput and convenient operation
  • 04
    Its counter-current tank structure ensures a high ore recovery rate
  • 05
    It is available in a series of specifications, with a drum diameter of φ750 mm to φ1500 mm and a drum length of 1000 mm to 5000 mm
