RTGX Series Permanent Magnet High-Intensity Magnetic Separator

The RTGX series permanent magnet high-intensity magnetic separator is a permanent magnet drum high-intensity magnetic separator. It generates a strong magnetic field on the surface of the separation drum through a permanent magnet squeeze magnetic circuit to separate weakly magnetic minerals.Currently, the main specifications of the RTGX series permanent magnet high-intensity magnetic separator include a separation drum diameter of 400 mm to 800 mm and a separation drum length of 1200 mm to 1600 mm.



Applications：

It is used for the separation of weakly magnetic minerals with a particle size of 0-20 mm, such as ilmenite, chromite, garnet, hematite, siderite, and limonite, with a magnetic field strength of over 1T. It can also be used for iron removal from various non-metallic minerals.
Technical Features：
  • 01
    Its squeeze magnetic circuit design provides high magnetic field strength and large magnetic field gradient, which can effectively capture weakly magnetic mineral particles
  • 02
    It has two magnetic circuit structures: a magnetic flipping circuit for high-precision separation of fine powders and a high-magnetic-force capture circuit for coarse-grained ores, which can meet customers' separation requirements in different scenarios
  • 03
    The separation drum uses variable frequency speed regulation, and the position of the ore separator plate is adjustable, which can effectively ensure the separation indicators
  • 04
    It can be combined with equipment such as vibrating feeders to form a complete set of equipment. Features a modular design for easy installation and maintenance
