GCG Type Electromagnetic Induction Roller High-Intensity Magnetic Separator

The GCG electromagnetic induction roller high-intensity magnetic separator is a dry electromagnetic high-field-strength magnetic separator. Its magnetic field intensity can reach 22,000 Gs, and it can separate minerals with a specific magnetic susceptibility range of 1.9×10⁻⁷ to 7.5×10⁻⁶ m³/kg. It is mainly available in two configurations: single-channel double-roller and double-channel four-roller.



Applications：
It is mainly used for the purification of non-metallic minerals such as quartz sand, beach sand, kyanite, and diamond, and can also be used to separate weakly magnetic minerals including hematite, ilmenite, manganese minerals, and garnet.
Technical Features：
  • 01
    It has a high magnetic field strength, reaching over 22,000 Gs
  • 02
    It is suitable for the dry separation of weakly magnetic minerals or non-metallic minerals smaller than 2 mm
  • 03
    The vertical arrangement of double rollers enables two consecutive separation operations on a single piece of equipment
  • 04
    The dual-channel feeding method enhances the processing capacity of a single unit
